Handheld Laser Methane Telemeter

Zetron is an original Handheld Laser Methane Telemeter manufacturer and supplier in China.Our company has launched laser methane leakage telemetry equipment, which is mainly used for natural gas leakage detection in natural gas and oil pipelines and urban pipeline corridors.

Model:MS104K-TDLAS-L

Send Inquiry

China Zetron Handheld Laser Methane Telemeter MS104K-TDLAS-L

One-touch operation design makes it easy for users to master the application quickly. Equipped with a high-performance auxiliary sight, it can accurately locate detection targets under strong light. It can be equipped with a multi-functional bracket for use in high-rise buildings and vehicle-mounted movements.

quick response.

The Handheld Laser Methane Telemeter test speed is fast, with 200 tests per second and a response time of 0.01s.

Detection distance exceeds 150 meters

Easily cope with the detection of urban gas-fired mid- and high-rise residential buildings.

Telemeter housing

Made of aluminum structure, surface oxidation anti-corrosion treatment, corrosion-resistant and anti-drop.

Handheld Laser Methane Telemeter Features:

1) Intelligent battery management technology ensures use time of more than 18 hours.

2) When the product is turned off, it has an effective standby time of 60 days.

3) Protection grade IP65, corrosion resistance and drop resistance.

4) Lens aspheric design, infrared anti-reflection coating

5) Easy to operate with only one button.

6) Waterproof shell design, suitable for industrial site use.

7) The Handheld Laser Methane Telemeter has a built-in Bluetooth module that can communicate with the mobile APP in real time.

Project	Parameters
Detect Gas	1 Kind
Features	Remote Measurement, Real-Time Continuous Long-Term Operation, Simple Operation, Hand-Held Design, Lightweight, Compact, Flexible, Fast Response
Examination Range	0ppm·M~50000ppm·M
Resolution	1 Ppm
Typical Accuracy	±5%
Detection Method	Handheld, Portable
Display	Color Screen Displays Methane Concentration, Internal Temperature And Pressure Of The Instrument In Real Time
Working Power Supply	2 X 4000ma Rechargeable Batteries
Maximum Power Consumption
Working Environment	-20-50°C
Data Storage	High Capacity
Print Function	None
Signal Output	None
Alarm Mode	Sound And Light Vibration
Fall Alarm	None
Wireless Transmission	Not Supported Yet
*Overall Dimensions: LWH*	292mm*60mm
Weight	0.55kg
Protection Level	Ip67
Standard Accessories	Instrument, Manual, Warranty Card, Certificate Of Conformity
Optional Accessories	Select According To Customer Needs
