Fix-installed Automatic Gas Leakage Monitoring System

New Fix-installed Automatic Gas Leakage Monitoring System Price

P20 Fix-installed Automatic Gas Leakage Monitoring System is designed to perform a 7×24 methane leakage detec- tion in Gas Plant,LNG facility,etc.With a maximum detection radium up to 150m,the response time less than 0.05s and the control of 360° horizontal and 180° vertical gimbal,the monitoring range covers a circular area up to 70000m² .

Fix-installed Automatic Gas Leakage Monitoring System is capable of working in both manual modeand auto- matic mode.By preset the check point,scanning path or the focused monitoring area on valves,flange joints or other facil- ities,the device is able to automatically operate the detec- tion tasks.

All leakage alarm data can be automatically saved in the corresponding management software -AlphaSupervisor, and users can easily retrieve or archive relevant alarm data.

Fix-installed Automatic Gas Leakage Monitoring System is regard as a regular network spot which can be easily accessed to any type of network topology.Also,to avoid the interruption caused by the AlphaSupervisor or the net- work in between,all preset data and alarm data Synchroni- zation Mechanism is built in P20 and AlphaSupervisor.

The new P20 launched this year has brought more advantages by revolutionary structural adjustments:

√ Explosion-proof grade update to Ex ib IIB T4 Highly reliable gimbal with longer lifetime

√ Introduce closed-loop control logic to greatly improve control accuracy.

√ Power consumption saved to 20W

√ 4 times smaller in size

√ 6 times lighter in weight

√ Plug and operate with easier configuration

√ New optional accessories:5G communication unit and photovoltaic /solar power supply.
