Vehicle Laser Methane Gas Detector

G10V vehicle laser methane gas detector has IP66 dustproof and waterproof feature, reliable and durable in daily outdoor inspections, supports probes, straps, belt buckles and other accessories and can be directly installed on a cart.Besides, G10V improves the response speed and increases the suction volume, and is suitable for electric vehicle inspections.

Model:G10V

Send Inquiry

TDLAS technology enables the directly concentration detection of ethane and the measurement results can be got in less than 1 second which is much faster and more intuitive than traditional methodsMoreover, Vehicle Laser Methane Gas Detector has significant advantages in terms of service life, anti-interference and operation.

Model	G10V	Explosion- proof Grade	Exib IIC T3 Gb
Measuring Principle	TDLAS	Range	0-100%VOL
Detection Targets	Methane(CH4)	Operating Temperature	-20°C ~ 50°C
Unit	ppm, %LEL, %VOL	Inspection APP	AlphaOne
Static Detection Limit	1 ppm	Operating Humidity	< 90%RH, No condensation
Pump rate	20 L/min	Power Supply	Li-ion Battery (10hours duration)
Response Time	0.2s	Size	208 x 78 x 53 mm
Protection Level	IP66	Weight	1.1 kg
Accessories	Handle probe	Optional Accessories	Bell probe/Carpet probe

Compact and sturdy structure with a detection capability of 1ppm in , 0.1 or methane floating in the air, laser detection equipment can perform real-time measurement more quickly.Especially suitable for trace gas detection.
