Portable 4 in 1 Gas Detector

The Zetron Portable 4 in 1 Gas Detector is a versatile device capable of detecting four different gases simultaneously. It combines the functions of multiple gas detectors into one compact unit. Ideal for various applications including industrial safety, environmental monitoring, and hazardous gas detection. The device provides real-time monitoring of gas concentrations, ensuring safety and compliance in diverse settings. We provide gas detector OEM/ODM serves.

Model:MS400

Send Inquiry

Product Description
Parameter
Application
Video

Zetron MS400 Portable 4 in 1 Gas Detector Factory

MS400 Series Portable 4 in 1 Gas Detector is up to 4 potential atmospheric hazards including oxygen, combustible and toxic gases, t he types of gases for detection are more than 500 types,MS400 is unparalleled in its versatility, capability and overall value.

It's adopted water-resistant line of portable gas detectors has transformed the market with its matchless array of features.

Continuously monitoring and displaying concentrations of up to 4 gases, the compact and lightweight MS400 Portable 4 in 1 Gas Detector was designed and engineered with an extensive host of applications in mind.

Gases to be detected	Range	Minimum reading	Response time T90
Combustible gas ( EX )	0-100%LEL	0.1%LEL	≤10 seconds
Methane ( CH4 )	0-100%LEL	0.1%LEL	≤10 seconds
Oxygen gas ( O2 )	0-30%Vol	0.01%Vol	≤10 seconds
Carbon monoxide ( CO )	0-100ppm	0.1ppm	≤25 seconds
Carbon dioxide ( CO2 )	0-500ppm	1ppm	≤20 seconds
Ozone ( O3 )	0-1ppm	0.001ppm	≤20 seconds
Hydrogen sulfide ( H2S )	0-10ppm	0.001ppm	≤30 seconds
Sulfur dioxide ( SO2 )	0-10ppm	0.001ppm	≤30 seconds
Nitric oxide ( NO )	0-10ppm	0.001ppm	≤30 seconds
TotalVolatileOrganic Compound gases ( TVOC )	0-10ppm	0.001ppm	≤30 seconds
Volatile gases ( PID )	0-10ppm	0.001ppm	≤30 seconds

Measuring gas	Hydrogen sulfide (H2S) Carbon monoxide (CO) Oxygen (O2) Sulfur dioxide (SO2)
Measuring range	H2S:0-100000ppm CO:0-10000ppm O2:0-100%Vol SO2:0-10000ppm and other ranges can be customized
Resolution	0.01 ppm 1 ppm 0.01 %Vol 0.1 %Vol Other resolution can be customized
Sensor type	Infrared Sensor Other Sensor:Laser , Electrochemical, Thermal conductivity, catalytic combustion, thermal conductivity, PID photoionization, and so on. Depending on the type of gas, range, field environment and user demand, Other sensors can be customized.
Measuring type	Built-in Pump sunction
Response time	T90<30s
Display	2.31-inch high-definition color screen
Alarm method	sound & light alarm; vibration alarm; sound & light + vibration alarm; turning off the alarm
Battery	DC3.7V, 4500mA high capacity rechargeable polymer battery
Data storage	Standard capacity is 100, 000 entries
Working temperature	-40 ℃ ~ + 70 ℃
Working humidity	≤10 ~ 95% RH
Housing	Rubber enclosure
Standard accessories	Manual, qualification certificate, warranty card, USB charger (including the data cable), belt clip, colorful packaging box (optional high-grade aluminum instrument case)
Dimension	160×70×28mm (L×W×H)
Weight	300g
Ex grade	Ex ia IIC T6 Ga Intrinsically safe type
Ingress protection	IP65

All the cases which requires the portable rapid detection of gas concentrations such as petroleum, chemical, pharmaceutical, environmental protection, combustion gas distribution, warehousing, smoke gas analysis, air governance, and so on.
