Laser Methane Leakage Scanning System

The structure of the P10 Laser Methane Leakage Scanning System from Zetron factory is composed of an explosion-proof pan/tilt, a laser hydrogen sulfide sensor, and a camera, and it has a SIL3 certification issued by a certification body. OEM/ODM gas detector

Model:P10

Send Inquiry

Zetron P10 Laser Methane Leakage Scanning System Made in China

P10 explosion-proof network HD integrated pan/tilt hydrogen sulfide detector is the latest explosion-proof monitoring equipment. This Laser Methane Leakage Scanning System can be used alone in an environment with flammable, explosive gas and combustible dust to achieve the purpose of monitoring the scene . It can be widely used in petroleum, chemical industry, oil depots, ships, drilling platforms, gas stations, gas stations, ports, mines, aerospace, military industry, steel, pharmaceuticals, fireworks production, food processing and other places.

Model	P10	Detection Targets	Methane (CHA)
Measuring Principle	TDLAS	Testing Laser Rating	Class I (Harmless to Naked Eye)
Static Detection Limit	5 ppm-m	Directing Laser Rating	Class IIIR (Harmful to Naked Eye)
Response Time	0.05s	Explosion -proof Grade	Exd IIC T6 Gb
Concentration Range	0-50,000 ppm-m	Protection Level	IP68
Max Detection Distance	150m	PTZ Camera Model	Customization Accepted
Data Interface	RS-485 ModBus / Ethernet / ALARM	Operating Temperature	-40°℃ - 60°℃
Power Supply	220VAC / 24VDC	Operating Humidity	< 90%RH, No condensation
Typical Power	50 W	PTZ Device Range	Horizontal +/-360° & Vertical +/-90°
PTZ Device Size	515 x 260 x 400 mm	PTZ Device Weight	32 kg

Versatile and practical, this device is ideal for short-term testing of air quality in buildings, workplaces and on the roadside. With a very fast response time, it delivers accurate readings and can locate sources of airborne dust and fumes even at very low concentrations.
